Features
● Display 9999 counts
● Jaw Opening Ф50mm/2.0"
● Auto & Manual Ranging
● Data Logging 28 groups
● True root mean suqare
● Bar Graph
● MAX/MIN Measurement
● Data Hold
● Display Backlight
● Low Battery Display
● RS232 Interface Windows OS
Features
● Display 9999 counts
● Jaw Opening Ф50mm/2.0"
● Auto & Manual Ranging
● Data Logging 28 groups
● True root mean suqare
● Bar Graph
● MAX/MIN Measurement
● Data Hold
● Display Backlight
● Low Battery Display
● RS232 Interface Windows OS
|
Specifications |
Range |
Resolution |
Accuracy |
|
AC Voltage |
100V/300V/600V |
0.1V |
±(1.2%+5) |
|
AC Current |
40A/100A/400A/1000A |
0.1A/0.1A/0.1A/1A |
±(2.0%+5) |
|
Active Power |
4kW/10kW/40kW/100kW |
0.01kW |
±(3.0%+5) |
|
600kW |
0.1kW |
±(3.0%+5) |
|
|
Apparent Power |
4kVA/10kVA/40kVA/100kVA/ |
0.01kVA |
±(3.0%+5) |
|
600kVA |
0.1kVA |
±(3.0%+5) |
|
|
Reactive Power |
4kVAr/10kVAr/40kVAr/100kVAr |
0.01kVAr |
±(4.0%+5) |
|
600kVAr |
0.1kVAr |
±(4.0%+5) |
|
|
Power Factor |
0.3~1 |
0.001 |
±(2.0%+2) |
|
Active Energy |
1kWh~9999kWh |
0.001kWh |
±(3.0%+2) |
|
Frequency |
20Hz~1000Hz |
0.1Hz |
±(0.5%) |
|
● Power Supply : 4×1.5V AA Batteries ● Product Size : 300mm×103mm×51mm/11.8"×4.1"×2.0" ● Product Weight : 640g/1.4lb ● Certifiacte : RoHS ● Safety Rating : CAT III 600V |
|
● Test Leads ● Alligator clip ● RS232C interface cable ● PC Data Record graph software ● Carry Case ● Batteries and User's manual |
