Features:
• Frequency 400Hz
• True RMS
• Overload Protection
• Transistor Test
• Diode
• Continuity
• LED
• Max Display: 2000
• CAT IV 600V / CAT III 1000V
• Relative
• Auto Power Off
• Data Hold
• Flashlight
• Battery: 9V
MASTECH
Features:
• Frequency 400Hz
• True RMS
• Overload Protection
• Transistor Test
• Diode
• Continuity
• LED
• Max Display: 2000
• CAT IV 600V / CAT III 1000V
• Relative
• Auto Power Off
• Data Hold
• Flashlight
• Battery: 9V
Features:
• Frequency 400Hz
• True RMS
• Overload Protection
• Transistor Test
• Diode
• Continuity
• LED
• Max Display: 2000
• CAT IV 600V / CAT III 1000V
• Relative
• Auto Power Off
• Data Hold
• Flashlight
• Battery: 9V
|
Spec |
Range |
Accuracy |
|
Resistance |
200Ω, 2KΩ, 20KΩ, 200KΩ, 2MΩ |
±(0.8%+5) |
|
200MΩ |
±(5.0%+10) |
|
|
DCV |
200mV |
±(0.5%+3) |
|
2V, 20V, 200V |
±(0.8%+3) |
|
|
1000V |
±(1.0%+5) |
|
|
ACV |
2V, 20V, 200V |
±(1.0%+5) |
|
750V |
±(1.2%+5) |
|
|
DCA |
2mA, 200mA |
±(1.0%+5) |
|
10A |
±(1.5%+10) |
|
|
ACA |
2mA, 200mA |
±(1.5%+5) |
|
10A |
±(1.8%+15) |
|
|
Frequency |
200KHz |
±(1.5%+10) |
|
℃ |
-20 ℃ ~400 ℃ |
±(2.0%+3) |
|
400 ℃ ~1000 ℃ |
±(2.0%+3) |
|
|
Capacitance |
2nF |
±(4.0%+20) |
|
20nF, 200nF, 2uF |
±(4.0%+15) |
|
|
200uF |
±(4.0%+20) |
|
product information |
|
|
- |
Accessories: Test leads, Manual, Temperature probe, 9V 6F22 Battery |
|
- |
Dimension:185mm*88mm*54mm |
|
- |
Weight:355g |
|
- |
Quantity:20 |
|
- |
Color Box:118mm*58mm*195mm |
|
- |
Carton Box: 420mm*325mm*260mm |
|
- |
SKU No.:MS890ACBGLO |
|
- |
EAN Code: 6974493900090 |
