Features
• Frequency: 1000Hz
• True RMS
• Overload Protection
• Unit Display
• Diode Test
• Continuity Check
• Non-Contact Voltage (NCV) Detection / Live Wire (Live) Recognition
• Max Display: 2000
• CAT III 600V
• Auto Power Off
• Data Hold
• Backlight
• Battery: 1.5V AAA*2
Features
• Frequency: 1000Hz
• True RMS
• Overload Protection
• Unit Display
• Diode Test
• Continuity Check
• Non-Contact Voltage (NCV) Detection / Live Wire (Live) Recognition
• Max Display: 2000
• CAT III 600V
• Auto Power Off
• Data Hold
• Backlight
• Battery: 1.5V AAA*2
|
Spec |
Range |
Accuracy |
|
Resistance |
200Ω, 2KΩ, 20KΩ, 200KΩ |
±(1.0%+5) |
|
200MΩ |
±(5.0%+10) |
|
|
DCV |
200mV, 2V |
±(0.5%+3) |
|
600V |
±(0.8%+5) |
|
|
ACV |
200mV, 20V, 600V |
±(1.0%+10) |
|
DCA |
200uA, 2mA, 20mA |
±(1.0%+5) |
|
200mA |
±(2.0%+5) |
|
|
10A |
±(3.0%+5) |
|
|
ACA |
200uA, 20mA |
±(1.8%+5) |
|
200mA |
±(2.5%+5) |
|
|
10A |
±(3.0%+5) |
|
|
Capacitance |
20nF, 2uF |
±(4.0%+15) |
|
200uF |
±(4.0%+20) |
|
|
℃ |
-20 ℃ ~ 0 ℃ |
±4 ℃ |
|
0 ℃ ~ 400 ℃ |
±(2.0%+3) |
|
|
400 ℃ ~ 1000 ℃ |
±(3.0%+3) |
|
|
℉ |
-4 ℉ ~ 50 ℉ |
±5 ℉ |
|
50 ℉ ~ 750 ℉ |
±(2.0%+5) |
|
|
750 ℉ ~ 1832 ℉ |
±(3.0%+5) |
|
|
Battery test |
1.5V, 3V, 9V |
- |
|
Frequency |
2KHz |
±(1.5%+5) |
|
product information |
|
|
- |
Accessories: Test leads, Manual, 1.5V*2 AAA Battery |
|
- |
Dimension:133mm*71mm*47mm |
|
- |
Weight:190g |
|
- |
Quantity:40 |
|
- |
Color Box:112mm*54mm*155mm |
|
- |
Carton Box: 570mm*335mm*250mm |
|
- |
SKU No.:MS830TCBGLO |
|
- |
EAN Code: 6974493900038 |
